Multi-ScreenMounts SystemX Product Components
Floor FixingKit
Vertical Column MountingRail
Floor BaseKit
FixingKits
ExtensionKit ScreenSpacer
Screen Interface Arms
BT8390-VESA200F
BT8390-SP
BT8380-180
BT8380-240
BT8390-070
BT8390-150
BT8390-175
BT8390-200
BT8390-EXT
BT8380-BASE
BT8380-CASTORS BT8380-FBFK
BT8390-VESA200T BT8390-VESA400F BT8390-VESA400T BT8390-VESA400MAF
 Fixed VESA 200 arms
 Screen Spacer for
quick installation
 2 heights available:
180cm and 240cm
 Available in Silver or Black
 4 lengths available:
70cm, 150cm, 175cm and 200cm
Includes
End Caps
Includes
End Cap  Combines Mounting
Rails together
BT8380-JPK
 Joins a Mounting Rail
to a Vertical Column
BT8390-WFK1
 5mm deep
Wall Fixing Kit
BT8390-WFK2
 19mm deep
Wall Fixing Kit
(Required when using
BT8380-VESA400MAF arms)
BT8390-CFK
 Collar Fixing Kit attaches
to B-Tech collars for
pole mounting.
 Floor Base includes
Levelling Feet  4”Braked Castors  Floor Base Fixing Kit
 VESA 200 arms with Tilt  Fixed VESA 400 arms  Fixed VESA 400 arms
with Micro-Adjustment
 VESA 400 arms with Tilt
Castors
The System X Range is available as a highly comprehensive component system which can be used to create bespoke video wall, menu
board and other multi-screen mounting solutions according to your requirements. Our online configuration tool (see next page) makes
it quick and easy to specify a complete solution that meets your needs.
Use with BT8390 Mounting Rail
Use with BT8390 Mounting Rail
Use with BT8380 Vertical Column
Supplied with
Finishing Trim
Strips
x2
B-Tech Registered Design Numbers on all System X components - please ask for details.
